Cascade Microtech 12000 8"Semiautomatic Probing Station w/Temptronic Chuck 12651

Manufacturer: Cascade Microtech

Model: 12651

Condition: For Parts or Not Working. This station is in Fair cosmetic condition with a few notable problems.  There is a silver electronic connection box on the rear of the station, which is broken off the base (the screws on back were stripped out) and it sits loose on the table. The temperature controlled chuck has a bad cooling hose and some minor corrosion on the fittings (the coolant in hoses behind the chuck looked clean and green).  The chamber cover (where probes and microscope objective insert) is missing a couple of standoffs and several screws, and the standoffs that remain are slightly bent.  The bottom of the table's legs look like they have floor wax spattered on them.  The shelf under the table has some residue which we are not sure what it may be.  The regulator for the head tilt air pressure is heavily scratched.  The table rests on thick rubber o-rings when deflated; these work well but are badly cracked.  The password for the software is written on the table's bumper in permanent marker.
The photos show the exact item(s) the buyer will receive.

Notes: This probing station is in Good working condition as far as we can test.  The view through the microscope, on video and in the eyepieces, is good.  The scope zoom and head lift work, but the head-down position hisses a little air leak constantly.  The stage mechanics work with software and joystick control, at all speeds.  Motorized Z-axis software control works.  Manual theta control works.  Coarse X and Y axis controls on the microscope tower, and coarse and fine manual focus controls work.  The manual platen lift works easily.  We did not test the vacuum valves.  The temperature control was able to control to a set temperature above ambient, but without coolant in the lines although the pump runs, it did not cool quickly.  The FLUID light on the controller is probably calling out the lack of coolant.  The Cascade software was able to verify communication with the station.  The E-stop button works and the keys unlock it easily.
No manuals, cords/cables, or additional items are included if not listed or shown.

Included:

• (1) Cascade 12651 Probing Station

Specifications:

• Manufacturer: Cascade Microtech
• Model: 12651
• Summit 12000-series semi-automatic probing station
• With MicroChamber for temperature-dependent characterization of devices
• Light- and EMI/RFI-tight testing enclosure
• Temptronic Thermochuck for -65º to +200ºC chuck temperature control (partial, see notes)
• Chamber top-hat ensures frost-free, condensation-free cold probing (requires inert gas)
• Motorized XYZ wafer stage also has manual adjustable XY and theta motion
• Thermochuck 8" vacuum chuck
• Joystick or software stage motion controls
• Easy-access roll out stage
• Locking e-stop button with 2 keys
• FormFactor Nucleus and Cascade Microtech WinCal XE software on Windows PC
• Optem A-Zoom 389220C2 New Technologies microscope with video and eyepiece viewing
• Super long working distance Mitutoyo objective lenses
• A-Zoom Laplink Variable intensity illuminator
• Manual microscope zoom
• Mitutoyo M Plan Apo 10x objective lens 378-802-2
• Mitutoyo M Plan Apo 5x objective lens 378-803-2
• Eyepieces: SUW10x
• Coarse and fine manual focus, plus motorized fine focus
• Coarse manual scope head XY translation
• Optem 38-31-40-000 ECL-15P illuminator
• Temptronic TPO3010B-2100-1 chuck temperature controller
• Optem 38-51-00-00 illuminator control
• Very high mass system to reduce vibration
• Kinetic Vibraplane 48" x 36" air-isolated vibration reduction table further reduces vibration
• Micromanipulators NOT included
• Large low-temperature chiller module NOT included
• Various issues, please read the description!

AS-IS

• No returns - No refunds - No exchanges
• By purchasing this item, you are agreeing to not seek reimbursement should the item not function to the manufacturer's specifications.
• Read the notes carefully to ensure you are buying something you can use
