Description

Manufacturer: Bertan

Model: 225-03R

Condition: Used. Comes in non-original packaging. This supply is in Fair cosmetic condition with lots of minor scuffs and scratches, and some minor adhesive label residues from prior use. Some of the legends are fading on the display panel. Please NOTE: We are 99% sure this uses an SHV type connector for J1 high voltage output, based on visual comparison with BNC and MHV connectors.
The photos show the exact item(s) the buyer will receive.

Notes: This supply is in mostly-working condition, except that the mA indicator doesn't illuminate. We are only equipped to measure up to 500V, so we strung 49.92 k ohms (5x 10k ohms resistors) in series on the output, and found the voltage indication matched our own meter. The current made sense, displaying 10.089mA at 500V and 1.008mA at 50V output. Maximum output voltage indication is 2998.9V, which we are unable to measure. The buttons, output High Voltage switch, polarity switch and adjustment knob all worked as expected. The adjustment knob deserves special mention because it is highly intuitive. Very-slow rotation gives slow-millivolts changes, and a big crank of the knob can give thousands of volts with a flick of the dial. The unit identifies itself at startup as 225.03. We did not test remote control or programming features. No other testing was done.
No manuals, cords/cables, or additional items are included if not listed or shown.

Included:

(1) Bertan 225-03R Power Supply

Specifications:

Manufacturer: Bertan Associates
Model: 225-03R
High Voltage DC Regulated Power Supply
Output power: 0-3 kV DC, 0-10 mA
5.5 digit front panel meter
With IEEE-488 digital interface communications
Arc and Short Circuit protected
Reversible polarity
Resolution: 0.1 V, 1 uA
Input power: Selectable 115/230 V (set for 115 V)
Remote analog programmable
2U rack mount size

Tested to full current (see photos)
