Big Ass Fans 24' Foot Dia 6-Blades Industrial Ceiling Fan w/ Variable Speed HVLS
- SKU:
- A15D001
- Shipping:
- Calculated at Checkout
- Condition:
- Used
- Warranty & Returns:
- 30-Day Guarantee
Description
Manufacturer: Big Ass Fans
Model: Basic 6
Condition: Used. This fan is in fair cosmetic condition with minor scuffs/scratches and dust from prior use/installation/removal.
Please NOTE: The controller's cables were cut, and your electrician will need to reconnect them. Power is via an included connector, but signals were sent over a CAT5e ethernet cable, which you can fit to the length you need. The photos show the exact item(s) the buyer will receive.
Notes: This fan is in good working condition. We removed this from the former installation, and watched it working before being switched off for the last time. No other testing was done. No manuals, cords/cables, or additional items are included if not listed or shown.
Included:
- (1) Big Ass Fans Basic 6 motor/gearbox/hub Assembly with Blade Retainers
- (1) Extension Tube with Mounting Brackets and Safety Cables
- (6) 11-foot Airfoils
- (1) Standard Controller CTL-LBLP-215-ENG-01
- Small pile of nuts & bolts
Specifications:
- Manufacturer: Big ASS Fans (Delta T LLC)
- Model: Basic 6
- 24-foot diameter ceiling fan
- Intuitive touch-screen Standard Controller
- 6x 11-foot airfoil blades with winglets
- Industrial-grade sealed gearmotor
- Variable speed (maximum 61 RPM)
- Power: 2.0HP (1.5kW)
- Input voltage: 200-240V 1 phase 50/60Hz 13.3A
- 2-foot extension tube with pivot-mounting bracket
- With clips and safety cables for mounting to I-beams and regular flat mount
-
Required Clearances:
- 10 feet above floor
- 7 feet below ceiling
- 2 feet from airfoil ends
-
Motor Inverter Drive: Big ASS Fans ESV152R02SLC582 (by Lenze AC Tech)
- Input: Single-phase 240V 50-60Hz 13.3A
- Output: Three-phase 0-230V 0-500Hz 7A
- Type 4X (indoor only) enclosure
-
Gearmotor: JD00012701
- type X_C 36 2 NUFA 28.2 P90 V1 DL, X_BN 90LA 4 230/460-60 IP56 CLF B5 N CUS
- 28.2:1
- Motor: Bonfiglioli Riduttori BN 90LA4
- Pivot Mounting Bracket: 007346-XXX
- Manufactured: 2019
